China type of vcb Manufacturer, Supplier, Factory

This 126KV HV Outdoor high-voltage SF6 single-phase circuit breaker is suitable for use in 72.5KV and 126KV three-phase AC 50HZ transmission and transformation systems. Its primary purpose is to regulate and safeguard these systems, but it can also function as a contact breaker and opener group, offering versatility in its applications.

The DJK series Electric energy Metering box is a versatile and reliable solution for electricity metering in high-rise buildings and residential areas. With a maximum current capacity of 63A, it can accommodate a variety of household needs. Additionally, its design can be customized to fit specific requirements, including the number of meter positions and external installation features. This meter box is ideal for households that require accurate and efficient electricity metering.

The SC(B) series epoxy resin dry-type transformer has been meticulously designed to prioritize safety. Its flame-retardant, fire-proof, and explosion-proof features ensure the highest level of safety. The encapsulated winding allows for direct installation in the load center, providing a maintenance-free and pollution-free solution. The scientific and rational design, in combination with the casting process, yields a product with lower partial discharge, reduced noise, and superior heat dissipation capacity. When equipped with forced air cooling, it can operate for extended periods under a 125% rated load.

In the past few years, as society and the economy have continued to evolve, the engineering construction industry has become more complex due to advancements in technology. There is a growing preference for switch equipment that is compact, requires minimal maintenance, and is smart. Both local and international switch manufacturers are actively working on 12KV 250A Medium Voltage Inflatable Cabinet Electrical Switchgear(C-GIS), or gas-insulated switchgear. This technology involves enclosing high-voltage components like busbars, circuit breakers, isolating switches, and power cables within a shell with reduced gas pressure.

The European style European style cable junction box cable branch box is a widely used cable engineering equipment in power and distribution network systems in recent years. Its main feature is bidirectional door opening, using through wall sleeves as connecting busbars, with significant advantages such as clear arrangement of small length cables and no need for large span crossing of three core cables. The cable joints used comply with the DIN47636 standard. Generally, a spiral fixed connection cable joint with a rated current of 630a is used

The CFB3 series miniature circuit breaker is suitable for overload and short circuit protection in AC 50/60Hz, rated voltage up to 230V/400V, and rated current up to 125A lines. It can also be used for infrequent on/off operations of the line under normal conditions. The CFB3-63 series circuit breaker is equipped with accessories such as CFB3-F auxiliary contacts, CFB3-FB auxiliary alarm contacts, CFB3-FL shunt release, CFB3-QY undervoltage release, CFB3-GY overvoltage release, CFB3-GQY overvoltage release, etc., providing convenience for the intelligent control of smart buildings. Overvoltage, undervoltage, and overvoltage/undervoltage are electronic release devices that are assembled and combined with circuit breakers or residual current circuit breakers. They are suitable for AC 50Hz/60Hz circuits with a rated voltage of 230V, and are used to protect against overvoltage, undervoltage, and overvoltage caused by line faults, avoiding damage to electrical equipment or inability to function properly due to fluctuations in grid voltage. The circuit breaker has an isolation function. Compliant with standards: GB/T10963.1, IEC60898-1, GB/T20645.
