The KYN28-12(Z) AC metal-clad switchgear 7.2KV 2500A High Current Electrical Switchgear is designed for use in 12kV-rated three-phase AC power systems operating at a frequency of 50Hz. It is utilized for the reception, distribution, and monitoring of electrical energy, as well as for circuit control and protection.

In recent years, with the progress of society, economy, and technology, engineering construction has become increasingly intricate. There is a rising demand for compact switch equipment that is low-maintenance and smart. Domestic and international switch manufacturers are working on 12KV 3150A Medium Voltage Electrical Switchgear Gas Insulation Switchgear, known as gas-insulated switchgear (C-GIS). This type of switchgear encases high-voltage elements like busbars, circuit breakers, isolating switches, and power cables in a shell with reduced gas pressure..

The KYN28-12(Z) 3.6KV 2500A New Type Of Armored Removable Ac Metal Enclosed Switchgear is designed for use in three-phase AC power systems with a rated voltage of 12kV and a rated frequency of 50Hz. Its primary function is to receive and distribute electric energy, as well as control, protect, and monitor circuits.

The advancement of society, economy, and technology has led to increased complexity in engineering construction. There is a growing demand for compact, low-maintenance, and intelligent switch products. Both domestic and foreign switch manufacturers are actively developing 12KV 1600A Medium Voltage Gas Insulated Electrical Switchgear (C-GIS), also known as gas-insulated switchgear. Gas-insulated switchgear refers to the encapsulation of high-voltage components, such as busbars, circuit breakers, isolating switches, and power cables, within a shell that maintains a lower gas pressure.

BWG Photovoltaic grid connected cabinet is an important component that undertakes centralized inverters and step-up transformers or AC combiner box step-up transformers. The incoming line of this photovoltaic grid connected cabinet uses a short-circuit breaker input or direct input, and the output uses a circuit breaker or load isolation switch. The busbar is connected with electroplated or purified wire, and provides secondary lightning protection. The maximum rated voltage of the system is AC690V, and the protection level is | P40 indoors and | P65 outdoors; The cables for secondary measurement and control include cables with a current greater than 2.5mm2, cables with a voltage of 1.5mm2, and cables with a control voltage greater than 1.0mm2. The measuring current transformer is a current transformer of level 0.5, and the measuring current transformer is a current transformer of level 0.25. Relevant functions can also be added according to customer requirements. This product adopts professional electrical design, is simple, beautiful, convenient for on-site wiring and maintenance, and ensures long-term stable operation of the equipment.

Low voltage Intelligent power quality hybrid compensation cabinet (after combining the complete set of devices) is installed in the cabinet, equipped with incoming circuit breakers and fast melting. Capacitor capacity can be any combination of 5kvar-60kvar; APF or SVG modules with capacities of 50A (35kvar), 100A (70kvar), and 100kvar are optional. Rear ventilation design with ventilation overcurrent mesh holes.
