The 126KV Outdoor high-voltage SF6 open type combination electrical appliances stands out as an integrated electrical device specifically designed for high-voltage power transmission and distribution systems. Its unique composition includes circuit breakers, disconnectors, earthing switches, current transformers, voltage transformers, and surge arresters, all enclosed in a metal housing filled with sulfur hexafluoride (SF6) gas, a highly effective insulating medium.

126KV Outdoor high-voltage SF6 ceramic column circuit breaker is a high-voltage sulfur hexafluoride device used in outdoor electrical systems operating at 126kV. It is designed to manage and safeguard power transmission and transformation networks. This breaker can serve as a switch and disconnection unit when needed. The breaker's innovative arc extinguishing technique involves thermal expansion and auxiliary blowing, and it incorporates a CTB-1 operating mechanism. It complies with the GB1984-2003 standard for AC High Voltage Circuit Breakers and ful specifications of the IEC62271-100:2001 standard for High Voltage Switchgear and Control Equipment Part 100: High Voltage AC Circuit Breakers established by the International Electrotechnical Commission.

The ZW43-12 series 12kv 630A Outdoor Automatical Vacuum Circuit Breaker are designed for outdoor use, with a rated voltage of 12kV and a frequency of 50Hz. These breakers are highly efficient, handling load currents, overload currents, and short circuit currents in power systems with ease. They are particularly suited for substations, industrial and mining establishments, and urban and rural distribution networks, where they provide protection and control, especially in applications that require frequent operation and automation. These breakers comply with several standards, including GB/T1984 for high-voltage AC circuit breakers, GB/T11022 for high-voltage switchgear and control equipment, and D1402 for AC high-voltage circuit breaker ordering technical conditions. Additionally, the circuit breaker can be paired with a controller to form a coordinated device, enabling remote control, monitoring, communication, and adjustment capabilities.

The 145KV 3150A Centre-break two post disconnector GW4 disconnector's conductive tube boasts a distinctive aluminum profile structure that enhances heat dissipation and fluid flow. This design minimizes the impact of the skin effect, allowing for. The tube's unique design makes it suitable for specific applications. Our product features state-of-the-art silver dedication to quality. This technology improves the adhesion of the silver plating layer, ensuring it meets standards. With appropriate contact pressure, the wear resistance of the contacts is improved, ensuring the silver plating layer remains intact even after extended use, providing long-term peace of mind. The soft connection, made of copper, features a silver-plated conductive contact surface, ensuring excellent conductivity and strong fluid capacity.

The 35kV 35KV PV Pad mounted Transformer is a combination transformer used for wind or photovoltaic power generation, which integrates a step-up transformer, high-voltage current limiting fuse, load switch, low-voltage switchgear, and corresponding auxiliary equipment. The capacity range is 500-6800KVA, and the voltage level is 35kV and below. It is suitable for various types of onshore, pond, and offshore photovoltaic and wind power plants.

The The GW8 series neutral point disconnecting switch is an outdoor device designed for use with AC 50Hz and 60Hz. It is intended to connect the neutral point of a transformer under no load conditions. The switch can be easily operated using either the CJ motor operating mechanism or the CS8 manual operating mechanism. Comprising a monopole and an operating mechanism, the GW8 series ensures smooth and hassle-free operation. The monopole includes a base, post-insulator, conductive arm, contact, and other components. The operating mechanism, whether it's the CJ motor operating mechanism or the CS8 manual operating mechanism, is crucial to the disconnecting switch process. It drives the conductive arm through the connecting rod, enabling the opening and closing of the disconnecting switch. is an outdoor device designed for use with AC 50Hz and 60Hz. It is intended to connect the neutral point of a transformer under no load conditions. The switch can be easily operated using either the CJ motor operating mechanism or the CS8 manual operating mechanism. Comprising a monopole and an operating mechanism, the GW8 series ensures smooth and hassle-free operation. The monopole includes a base, post-insulator, conductive arm, contact, and other components. The operating mechanism, whether it's the CJ motor operating mechanism or the CS8 manual operating mechanism, is crucial to the disconnecting switch process. It drives the conductive arm through the connecting rod, enabling the opening and closing of the disconnecting switch.
