China VCB for indoor electrical installations Manufacturer, Supplier, Factory

This circuit breaker is a multifunctional low-voltage protection device designed for distribution systems with AC 50Hz, rated voltage below 400V, and rated current below 63A. It is suitable for industrial, commercial, and civilian power networks. Its core functions integrate security protection, equipment protection, and intelligent monitoring, which can significantly improve the reliability and operation efficiency of the distribution system. Core functional highlights: 1. Safety protection 1) Personal safety assurance: Through high-precision residual current detection technology (RCD), indirect contact protection is provided, effectively reducing the risk of electric shock. 2) Equipment and line protection: Integrated overload and short circuit dual protection mechanism, accurately cutting off fault current, avoiding electrical fires and equipment damage. 2. Intelligent monitoring and early warning 1) Leakage pre-alarm function: Real-time monitoring of residual current in the circuit. When abnormal leakage (such as insulation degradation) is detected, an alarm signal is output through a passive normally open contact (dry contact). It can be linked to SCADA, fire protection system or sound and light alarm device without an external power supply to achieve early warning of faults and ensure power supply continuity. 2) Flexible threshold configuration: supports custom setting of leakage alarm values, adapting to sensitivity requirements of different scenarios (such as 30mA/100mA adjustable). 3. Diversified control ability Line and motor control: suitable for occasional switching operations of distribution lines or intermittent start-stop control of small motors, meeting the requirements of nonfrequent operation scenarios. Typical application scenarios: 1) Key power supply areas: places with high requirements for power continuity, such as data centers and hospital IT systems, have alarm nontrip mechanisms to avoid accidental power outages. 2) Equipment protection: Front-end protection for devices such as frequency converters and outdoor electrical cabinets that are susceptible to electrical leakage or environmental impact. 3) Intelligent operation and maintenance: By connecting to the building management system (BMS) through touch signals, remote monitoring and preventive maintenance can be achieved. Product advantages: 1) High reliability: thermal magnetic double trip structure, balancing overload delay protection and short-circuit instantaneous action characteristics. 2) Flexible expansion: an optional communication module, supporting remote status monitoring and fault diagnosis. 3) Easy installation: Standardized modular design, compatible with mainstream rail installation, suitable for compact distribution boxes. Summary: This circuit breaker is designed with the concept of "warning first, safety oriented", which ensures the safety of personnel and equipment while maximizing the stability of system operation. It is the preferred protective device for modern intelligent distribution systems.

The GGD-type Low voltage AC distribution switchgear is a versatile and reliable solution for various power distribution needs. It is well-suited for AC 50Hz distribution systems with a rated working voltage of 380V and a maximum current rating of 6300A, making it a great choice for power plants, substations, mining operations, and other heavy-duty power users. This distribution cabinet is designed with a focus on safety, efficiency, and adaptability, offering a range of features such as high breaking capacity, strong stability, flexible electrical configurations, convenient combination options, and a practical and novel structure. Additionally, it offers a high level of protection, making it an ideal replacement for low-voltage switchgear sets.

KYN28-12(Z) AC metal armored switchgear 3.6KV 2000A High Current Switchgear Electrical Equipment is a versatile and reliable solution for managing three-phase AC power systems with a rated voltage of 12kV and a frequency of 50Hz. Its primary function is to efficiently distribute and control electric energy, while also providing protective measures and monitoring capabilities to ensure the safety and efficiency of the system.

The New Armored Removable AC Metal-Enclosed Switchgear, a testament to advanced switchgear technology, the 35kv 1200 amp 1250a mv switchgear is specifically crafted for three-phase AC power systems with a rated voltage of 35kV. It accommodates rated currents ranging from 630a to 3150a, and operates at a frequency of 50Hz. This cutting-edge equipment not only facilitates the efficient transfer and distribution of electric energy but also offers robust control, protection, and monitoring capabilities for electrical circuits, ensuring optimal performance and reliability.

The DZ47-63 series miniature circuit breaker is designed for use in lighting and motor distribution systems, protecting against overloads and short circuits. Its innovative design, lightweight construction, and dependable operation make it a high-performance solution.

The ZN85-40.5/40.5KV Indoor High Voltage Vacuum Circuit Breaker for switchgear, designed for use in AC 50Hz systems with a rated voltage of 40.5kV, is a durable solution for switching load current, overload current, and fault current in industrial and mining facilities, power plants, and substations. Its upper and lower layout structure, reducing its overall depth, is a testament to its durability. The specially designed spring operating mechanism, tailored to suit the upper and lower layout configuration, ensures simplicity, optimal output curve, and performance that aligns with the requirements of 40.5kV vacuum circuit breakers. This circuit breaker's ability to handle frequent operation and its resilience in harsh operating conditions in various environments instill confidence in its durability.
