China Isolating switch outdoor installation Manufacturer, Supplier, Factory

The KXAIS-12 series Solid Insulated Ring Main Unit Rmu Electrical Switchgear is a fully insulated, fully sealed, and anti condensation ring main unit equipment that is based on solid sealing and vacuum insulation technology, and is independently developed using epoxy resin (APG process) to pour the three position switch (isolation, grounding), circuit breaker vacuum arc extinguishing chamber, and main circuit primary conductive components together to form the insulation component body. It is assembled from insulated busbars and other insulation connectors to form a fully insulated, fully sealed, and anti condensation ring main unit.

BWG Photovoltaic grid connected cabinet is an important component that undertakes centralized inverters and step-up transformers or AC combiner box step-up transformers. The incoming line of this photovoltaic grid connected cabinet uses a short-circuit breaker input or direct input, and the output uses a circuit breaker or load isolation switch. The busbar is connected with electroplated or purified wire, and provides secondary lightning protection. The maximum rated voltage of the system is AC690V, and the protection level is | P40 indoors and | P65 outdoors; The cables for secondary measurement and control include cables with a current greater than 2.5mm2, cables with a voltage of 1.5mm2, and cables with a control voltage greater than 1.0mm2. The measuring current transformer is a current transformer of level 0.5, and the measuring current transformer is a current transformer of level 0.25. Relevant functions can also be added according to customer requirements. This product adopts professional electrical design, is simple, beautiful, convenient for on-site wiring and maintenance, and ensures long-term stable operation of the equipment.

The S-M series three-phase oil-immersed transformer is not just robust, it's also a game-changer in terms of efficiency and energy savings. Its fully sealed and oil-filled corrugated tank allows for thermal expansion and efficient heat dissipation, while the innovative insulation provides enhanced protection against short circuits. The windings are crafted from arranged in a multi-layer cylindrical configuration, and all fasteners are treated to prevent loosening. This transformer's exceptional efficiency and minimal energy losses mean potential significant power consumption reduction, a feature that has made it a staple in various industries, including power generation, transmission, and distribution, as well as industrial, mining, and transportation applications.

The New Armored Removable AC Metal-Enclosed Switchgear, a testament to advanced switchgear technology, is specifically crafted for three-phase AC power systems with a rated voltage of 35kV. It accommodates rated currents ranging from 630a to 3150a and operates at a frequency of 50Hz. This cutting-edge equipment not only facilitates the efficient transfer and distribution of electric energy but also offers advanced control, protection, and monitoring capabilities for electrical circuits, ensuring optimal performance and reliability, and most importantly, safety.

ZCW10-40.5G /T1600-31.5 Outdoor high-voltage SF6 open type combination electrical appliances is a complete set of units using air as external insulation SF 6 gas as arc extinguishing medium Combined electrical appliances.The control and protection of the three-phase AC 40.5kV transmission anddistribution system can also be used to connect circuit breakers and open and close capacitor banks.Suitable for the land shortage of urban substation, enterprise substation, mountain substation.

The The GW8 series neutral point disconnecting switch is an outdoor device designed for use with AC 50Hz and 60Hz. It is intended to connect the neutral point of a transformer under no load conditions. The switch can be easily operated using either the CJ motor operating mechanism or the CS8 manual operating mechanism. Comprising a monopole and an operating mechanism, the GW8 series ensures smooth and hassle-free operation. The monopole includes a base, post-insulator, conductive arm, contact, and other components. The operating mechanism, whether it's the CJ motor operating mechanism or the CS8 manual operating mechanism, is crucial to the disconnecting switch process. It drives the conductive arm through the connecting rod, enabling the opening and closing of the disconnecting switch. is an outdoor device designed for use with AC 50Hz and 60Hz. It is intended to connect the neutral point of a transformer under no load conditions. The switch can be easily operated using either the CJ motor operating mechanism or the CS8 manual operating mechanism. Comprising a monopole and an operating mechanism, the GW8 series ensures smooth and hassle-free operation. The monopole includes a base, post-insulator, conductive arm, contact, and other components. The operating mechanism, whether it's the CJ motor operating mechanism or the CS8 manual operating mechanism, is crucial to the disconnecting switch process. It drives the conductive arm through the connecting rod, enabling the opening and closing of the disconnecting switch.
